Optium® Acrylic™ Product Data
|
Optium® Acrylic™ 3.0mm |
Optium® Museum Acrylic™ 6.0mm | Optium® Museum Acrylic™ with OP-3 UV Filtering 3.0mm (also available in 4.5mm) |
| Physical Characteristics | |||
| Size | 48x96in./121.92x243.84cm | 72x120in./183x305cm | 48x96in./121.92x243.84cm |
| Availability | 1 lite box/32 sq. ft. | 1 lite box/ 60 sq. ft. | 1 lite box/32 sq ft. |
| Thickness | 1/8in./3.0mm +/-0.3mm | 1/4in./6.0mm +/-0.3mm | 1/8in./3.0mm +/-0.3mm |
| Weight | 22 lbs. per lite | 89 lbs. per lite/1.5 lbs. per sq. ft. | 22 lbs per lite |
| Substrate | Clear abrasion-resistant acrylic | Clear abrasion-resistant acrylic | Clear abrasion-resistant OP-3 acrylic |
| Coating | Sputtered anti-reflection | Sputtered anti-reflection | Sputtered anti-reflection |
| Performance Data | |||
| UV Protection 300-380nm | 93% | 98% | 98% |
| Light Transmission | 97% | 97% | 97% |
| Light Reflection | <1.6% | <1.6% | <1.6% |
| Resistivity | 1x1010(Ohms/Sq.) | 1x1010(Ohms/Sq.) | 1x1010(Ohms/Sq.) |
| Anti-Static | Yes | Yes | Yes |
| Anti-Reflective | Both Sides | Both Sides | Both Sides |
| Outgassing | None (less than 200° F) | None (less than 200° F) | None (less than 200° F) |
Information courtesy of Tru Vue®
